ATO 10hp VFD Single To 3 Phase, 220V/230V/240V Single Phase Input Three Phase Output VFD Variable Frequency Drive, 10hp 1 Phase To 3 Phase VFD Inverter Converter (10hp 7.5 KW, 34A)

This VFD can run 3-phase 220v motor with 200-230V AC single or three phase power supply The vfd cannot be used as a power source,It can only be used to connect three-phase motors Basic parameter for 3 phase 50/60Hz motor Set p0.03=50/60, p0.04=50/60, p0.06=50/60，p2.02=50/60 ( Note ：The default setting of the VFD is 50hz, which can be directly connected to the motor for driving) Aluminum base: This ensures the stability of the product and increases the heat dissipation capacity of the fan Control panel UP: Progressively increase data or function codes. DOWN: Progressively decrease data or function codes. DATE/SET: Progressively enter menu and confirm parameters SHIFT: Switch monitoring parameters at monitoring state, at secondary menu, move data box to process editing position. QUICK/JOG:Determined by function code P7.03=(0:Display stautsa switching,1:jog operation,2:switch between forward and reverse,3:Clear the up/down terminals settings,4:Quick debugging mode) Multiple terminals Unlike other inexpensive VFDS, this VFD has two sets of terminal functions,Rich of digital and analogy control terminals for versitile control,optional MODBUS (RS485) extension,diversified parameter setting. supports mcah3 function and RS-485 communication (For more information, you can contact the seller, we will send you a video of the basic functions of VFD) Support brake resistance installation function, faster motor braking Easy PLC function can realize 16 legs of speed and inverter control function With extremely strong anti-jamming capability Low output ratting torque 0.5HZ-150%, low speed running ability Broad voltage working area, normal running in 304V-456V Auto voltage regulation (AVR) technique, for ensuring the inverter load capability Dead-time compensation and auto torque slip compensation function, can realize 180% high orque output at low frequency 0.25Hz Supports mcah3 function and RS-485 communication//Supports remote potentiometer speed control and remote switch start/stop Easy to connect the motor/easy to use The VFD has the advantages of low noise and low electromagnetic interference Low failure rate/Designed to be non-flammable Achieved CE listed Support DPS vector control1 Year replace . If there is an error code in the product and you do not know how to operate, please contact the seller
